The sixth-generation Seagate Cheetah 15K.6 has the highest sequential and transactional performance of any 3.5-inch drive in the enterprise market and delivers a 61 percent improvement in watts/GB at idle over the prior generation.
Device Location: Internal
Form Factor: 3.5"
Storage Capacity: 300 GB
Supports Data Channel: Fibre Channel
Swap Capability: Hot
Installed Cache Memory Storage Capacity: 16 MB
Heads Quantity: 6
Rotational Speed: 15000 rpm
Average Rotational Delay: 2 ms
Average Seek Time: 3.9 ms
Track-to-Track Seek Time: 0.4 ms
Internal Data Bit Rate: 2225 Mbps
External Data Bit Rate: 400 MB/sec
Non-Recoverable Errors: 1 per 10^16
Hard Drive Features: Perpendicular recording Seagate PowerTrim
Compliant Storage Standards: S.M.A.R.T.
FC-AL Interface Connector Type: 40-pin SCA-2
FC-AL Interface Quantity: 1
Platform Compability: PC
Maximum Operating Ambient Temperature: 55 °C
Minimum Operating Ambient Temperature: 5 °C
Maximum Operating Humidity: 95 %
Minimum Operating Humidity: 5 %
Maximum Non-Operating Ambient Temperature: 70 °C
Minimum Non-Operating Ambient Temperature: -40 °C
Maximum Non-Operating Humidity: 95 %
Minimum Non-Operating Humidity: 5 %
Maximum Power Consumption: 16.1 W
Minimum Power Consumption: 11.2 W
Shock Tolerance Operating: 60G @ 2ms
Shock Tolerance Storage: 250G @ 2ms
Vibration Tolerance Operating: 1G @ <400Hz
Vibration Tolerance Storage: 2G @ <400Hz
Typical Operating Noise Level: 36 dB
Depth: 146.99 mm
Height: 26.11 mm
Width: 101.85 mm
Nominal Weight: 0.694 kg
Warranty Products returnable: Yes
Warranty Term (month): 60 month
Warranty validation Criteria: Serial Number
Pieces in pack: 1
