Key Features and Benefits

• Purpose-built for enterprise-class nearline applications


• Lowest operating power for enterprise-class drives


• Additional on-demand power savings for idle periods with PowerChoice

Device Location: Internal
Form Factor: 2.5"
Storage Capacity: 500 GB
Supports Data Channel: Serial ATA II-300
Installed Cache Memory Storage Capacity: 32 MB
Sector Capacity: 512 B
Rotational Speed: 7200 rpm
Average Rotational Delay: 4.16 ms
Track-to-Track Seek Time: 1 ms
Maximum Seek Time: 9.5 ms
Internal Data Bit Rate: 95 MB/sec
External Data Bit Rate: 300 MB/sec
Non-Recoverable Errors: 1 per 10^15
Mean Time Between Failures: 1200000 hr
Compliant Storage Standards: S.M.A.R.T.
SATA Interface Quantity: 1
SATA Interface Connector Type: SATA 7-pin
Maximum Operating Ambient Temperature: 55 °C
Minimum Operating Ambient Temperature: 5 °C
Maximum Non-Operating Ambient Temperature: 70 °C
Minimum Non-Operating Ambient Temperature: -40 °C
Minimum Power Consumption: 3.5 W
Shock Tolerance Operating: 70G @ 2ms
Shock Tolerance Storage: 400G @ 2ms
Vibration Tolerance Operating: 0.5G @ <400Hz
Vibration Tolerance Storage: 2.4G @ <500Hz
Typical Operating Noise Level: 26 dB
Depth: 100.5 mm
Height: 70 mm
Width: 14.8 mm
Nominal Weight: 0.196 kg
Warranty Products returnable: Yes
Warranty Term (month): 60 month
Warranty validation Criteria: Serial Number
Pack Weight Brutto (kg): 0.25 kg
Pieces in pack: 1
