Olympus E-M1 Body black incl. Charger & Battery Micro Four Thirds MFT - OM-D Camera digitalni fotoaparat V207010BE000

PRODUCT HIGHLIGHTS

16.3MP Live MOS Sensor
TruePic VII Image Processor
Micro Four Thirds System
FAST Dual Phase- & Contrast-Detection AF
Interactive 2,360k-Dot EVF
3.0" 1,037k-Dot Tilting LCD Touchscreen
5-Axis Image Stabilization with IS Auto
Built-In Wireless Connectivity
10 fps and 1/8000 sec. Top Shutter Speed
Dust/Splash/Freezeproof Mag. Alloy Body



OVERVIEW

The black Olympus OM-D E-M1 Mirrorless Micro Four Thirds Digital Camera is a compact, ergonomically designed camera featuring a 16.3 megapixel Live MOS sensor and TruePic VII image processor to produce high-resolution still imagery and full HD 1080p video with notable low-light quality and high-speed performance. The combination of these two technologies enables a high sensitivity range from ISO 100-25600 and also contributes to a top 1/8000 sec. shutter speed and continuous shooting up to 10 fps. The sensor also lends itself to an enhanced FAST autofocus system that utilizes dual contrast- and on-chip phase-detection focusing methods to quickly and accurately acquire focus with selectable focus areas for even greater precision.

Also benefitting image sharpness is in-body 5-axis image stabilization that compensates for vertical, horizontal, and rolling camera shake. IS-Auto mode can also be employed, which intelligently detect both vertical and horizontal panning and disengages image stabilization along the detected axes to provide stabilization when photographing moving subjects.

Both a high-resolution electronic viewfinder and tilting touchscreen monitor are available for live view monitoring, image playback, and menu navigation. The interactive EVF features a 2,360k-dot resolution and 1.48x magnification for comfortable eye-level viewing with the ability to preview image effects in real-time. Alternatively, the 3.0" 1,037k-dot tilting touchscreen LCD monitor can tilt upward 80° or downward 50° to suit working from high and low angles and its touchscreen design provides an intuitive means for controlling settings and navigating through the menu system. Both of these viewing mechanisms are housed within the ruggedly-designed dust-, splash-, and freezeproof magnesium alloy body. A large grip is integrated into the construction to provide a comfortable means for handling the camera and also facilitates more efficient control over a wide range of camera settings. Additionally, the incorporation of an X-sync socket, HDMI port, external microphone jack, and hot shoe also add to the E-M1's overall functionality.

For refined off-board control and image sharing, built-in wireless connectivity is available and, when paired with the Olympus O.I. Share app for iOS and Android mobile devices, remote sharing and control over the camera is possible. QR Code Connect provides a simple, seamless way of linking mobile devices to the camera and the option of utilizing a smartphone to embed locational data into the image files for geotagging is also supported.

16.3MP Live MOS Sensor and TruePic VII Image Processor
The 16.3 megapixel Live MOS sensor and TruePic VII image processor work in concert to enable high resolution still imagery, full HD video recording, and notable low-light quality sensitivity to ISO 25600. The combination of these two technologies also helps to promote high-speed performance throughout the camera system, including a top shutter speed of 1/8000 sec. with a mechanical shutter, a continuous shooting rate up to 10 fps with Tracking AF, and continuous 6 fps shooting with continuous autofocus.

Additionally, full HD 1080p movie recording is supported at 30 fps with stereo sound in either the MOV or AVI format. A Direct HD Movie Button is available for instant access to movie recording and a range of Art Filters and effects can be applied while recording for more creative control. An external microphone jack is also available to enhance the quality of sound during recordings.
FAST Dual Phase- and Contrast-Detection AF
The sensor also affords dual-mode auto focusing that utilizes both contrast- and on-sensor phase-detection methods to quickly and accurately acquire focus. The contrast-detection system employs 81 areas while the phase-detection method uses 37 areas and, when combined, make the FAST (Frequency Acceleration Sensor Technology) focusing system that is able to reap the benefits from both technologies to produce all-around focusing that is equally fast as it is precise. Four different AF area sizes can be used, too, with the smallest, Super Spot AF, enabling pin-point precision that is well-suited to macro and close-up imagery. Selectable 3 x 3 groups within the 81 areas in contrast-detection can also be paired according to the subject type being photographed and a 0.044 second focus lag time ensures quick focusing for moving subjects.
5-Axis Image Stabilization
In-body image stabilization helps to minimize the appearance of camera shake with any lens in use and compensates for camera movements up to the equivalent of five shutter speed steps. Furthermore, this unique image stabilization system works across five axes, versus the conventional two axes, and compensates for vertical angle rotation, horizontal angle rotation, horizontal shift, vertical shift, and rolling camera shake movements. This range of detected movements serves to benefit traditional still image shooting as well as movie recording and working with moving subjects more effectively. Furthering the effectiveness of the 5-Axis IS, IS-Auto mode is available to detect both vertical and horizontal panning to automatically deactivate image stabilization along the detected panning axis to enable greater stability when tracking moving subjects.
Interactive EVF and 3.0" Tilting Touchscreen
For eye-level viewing, a bright 2,360k-dot electronic viewfinder is integrated into the design and features a smart eye detect function, 29ms image display lag time, and 1.48x magnification. This finder enables realistic, high resolution viewing in a comfortable position that is especially beneficial when working in bright conditions. The viewfinder also allows for real-time visualization of different camera settings, including aspect ratio, highlight and shadow, and magnification. The adaptive brightness settings also enable easier viewing in different lighting conditions, with the brightness being set according to surrounding conditions to better simulate the use of an optical viewfinder.

In addition to the viewfinder, a large 3.0" 1,037k-dot tilting touchscreen LCD monitor is also available for live view monitoring, image playback, and menu navigation. The monitor's design can tilt 80° upward and 50° downward, making it well-suited to use from both high and low angles. The intuitive touchscreen control offers a range of additional functionality, too, including the ability to touch to release the shutter, select the focusing point, magnify the image, apply filter effects, and navigate through images and settings.
Body Design
Constructed from magnesium alloy, the E-M1 features a dust-, splash-, and freezeproof design that enables full-functionality in adverse conditions. The rugged metal body is also designed to be as lightweight and ergonomic as possible to support comfortable use for long shooting durations.



The body is also designed to provide the most intuitive and efficient control over crucial camera settings. Eight customizable 'direct buttons' are available and can control a range of settings simply by pressing the designated button and rotating the main or sub dials. A locking mode dial is also incorporated into the large ergonomic grip and 2 x 2 dial control provides enhanced manipulation over exposure settings through the use of two dials and a function lever. Also integrated into the body's design is an X-sync socket for direct linking of external strobes; an HDMI output for connection to an HDTV for high-quality photo and movie playback; and USB and component video connections are available, too. A proprietary accessory port and hot shoe are available as well for connecting external flashes, the Olympus PENPAL, and MAL-1 Macro Light.
Built-In Wireless Connectivity
By using the O.I. Share app, wireless control of the E-M1 is possible through using linked iOS and Android mobile devices. The mobile device can be used to preview compositions, choose a specific AF point, and release the shutter via the intuitive app interface. The self-timer can also be set and access privileges can be given for others to download select images directly from the camera. Linking of mobile devices to the camera is possible through an intuitive QR Code Connect system, which displays a unique QR code on the camera's monitor which can then be recognized by a mobile device for instant linking. Additionally, smartphones can be used to embed GPS information into image files' metadata for geotagging applications, which can then be plotted to interactive maps through Olympus Viewer 3 or other applications supporting GPS log data.
In-Camera Image Control
The Color Creator feature allows for adjusting hue and chroma directly in the EVF with results visible in real-time. This, coupled with an intuitive GUI, permits more finite and exacting control over the color balance of an image.
HDR Preview emulates the finalized look of an HDR image in the viewfinder prior to the camera processing the images together, allowing greater control and selectivity over how extended dynamic range images are taken. HDR photos are possible with up to a 12 EV-wide range of bracketed shots.
12 Art Filters are available for creatively enhancing imagery and movies and can be further adjusted by using filter variation, art effects, and Art Filter Bracketing: Pop Art, Soft Focus, Pale & Light Color, Light Tone, Grainy Film, Pin Hole, Diorama, Cross Process, Gentle Sepia, Dramatic Tone, Key Line, and Water Color.
Photo Story allows recording of a scene from multiple viewpoints, which are then composited into a single image using a range of pre-defined formats.
Live Bulb mode allows you to view the progression of exposure during a bulb exposure in real-time and a live view histogram shows how the exposure is built-up across all points of the image.
Live Control is an advanced control panel system that displays the image and camera controls all at once; giving a broader range of controls when working in either manual or automated shooting modes.
MF (Magnified Focus) Assist and Magnification Display provide up to 10x enlargement of a scene to benefit gaining critical focus when working in either manual or autofocus modes.
Both JPEG and RAW file types can be edited in-camera in order to quickly crop an image, remove red-eye, and convert an image to black and white amongst other editing options.
iAUTO is an intelligent automated shooting mode that allows the camera to select from 42 pre-determined modes based on the detected scene type in order to optimize camera settings. iAUTO is also effective when working with moving subject matter and can adjust basic exposure settings in order to minimize subject blur.
Multiple Exposure shooting allows for the stacking of sequential exposures within the same frame for creative results.
Other Camera Features
Focus Peaking benefits working with manual focus by highlighting edges of contrast in either black or white to provide a more objective means for determining critical focus.
Fine Detail II technology automatically corrects for chromatic aberration based on the specific lens in use. Natural-appearing high-resolution quality is attained by applying intelligent sharpening techniques based on the lens' focal length and aperture value being used.
The Dust Reduction System, in combination with the Supersonic Wave Filter (SWF) self-cleaning ultrasonic sensor unit, works to eliminate dust particles on the sensor surface by silently vibrating 30,000 times per second to dislodge any stray particles from affecting image quality. The entire sealed unit is integrated into the stabilizer and sensor assembly.
Interval shooting permits sequential recording of 1-999 shots, with 1 second to 24 hour intervals, to easily shoot a series of consecutive photos. Furthermore, the series of images can be converted to a time-lapse movie for more simplified playback.
An AF illuminator aids in precise focusing under low-light conditions.
A slideshow with sound can be created in-camera using a range of effects, including fade-in/out techniques, control over the movie and still image mix and speed, and the option of adding a soundtrack.
A 4x digital teleconverter can be used when recording movies to extend the effective reach of any lens with intuitive zooming control on the touchscreen LCD.
Face Detect, Face Priority, and Eye Detection allow you to select different priorities for basing focus and exposure on. Up to eight separate faces can be detected and Eye Detection allows you to select either the right or left eye to prioritize.
A built-in level gauge aids in creating perfectly level compositions based on the horizon and architectural elements within the scene.
Shadow Adjustment Technology corrects for extreme contrast between shadows and highlights within an image either during the exposure or through in-camera image editing.
Four different aspect ratios can be used for both still images and movie recording: 4:3, 3:2, 16:9, and 1:1.
Language support: English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish, Portuguese, Swedish, Norwegian, Finnish, Croat, Slovenian, Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian, Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, and Thai.



Imaging
Lens Mount Micro Four Thirds
Camera Format Micro Four Thirds (2x Crop Factor)
Pixels Actual: 16.8 Megapixel
Effective: 16.3 Megapixel
Max Resolution 15.9 MP: 4608 x 3456
Sensor Type / Size MOS, 17.3 x 13 mm
File Formats Still Images: JPEG, MPO, RAW
Movies: AVI, MJPEG, MOV, MPEG-4 AVC/H.264
Audio: Linear PCM (Stereo), WAV
Bit Depth 12-bit
Dust Reduction System Yes
Memory Card Type SD
SDHC
SDXC
Image Stabilization Sensor-Shift, 5-Way
AV Recording
Video Recording Yes, NTSC/PAL
Resolution 1920 x 1080: 30 fps
1280 x 720: 30 fps
640 x 480: 30 fps
Aspect Ratio 4:3, 16:9
Video Clip Length Up to 29 Min
Audio Recording Built-in Mic: With Still Images & Video, Stereo
Optional External Mic: With Still Images & Video
Focus Control
Focus Type Auto & Manual
Focus Mode Continuous-servo AF (C), Manual Focus (M), Single-servo AF (S)
Autofocus Points Contrast Detection: 81
Phase Detection: 37
Viewfinder/Display
Viewfinder Type Electronic
Viewfinder Pixel Count 2,360,000
Viewfinder Eye Point 21.00 mm
Viewfinder Coverage 100%
Viewfinder Magnification Approx. 1.48x
Diopter Adjustment - 4 to +2 m
Display Screen 3" Wide Touchscreen Tilting LCD (1,037,000)
Screen Coverage 100%
Exposure Control
ISO Sensitivity Auto, 100-25600
Shutter Type: Electronic & Mechanical
Speed: 60 - 1/8000 second
Type: Electronic & Mechanical
Speed: 30 - 1 seconds in Bulb Mode
Remote Control RM-UC1 (Optional)
Metering Method Center-weighted average metering, Multi-zone metering, Spot metering
Exposure Modes Modes: Aperture Priority, Art Filter, Bulb, Manual, Programmed Auto, Scene Selection, Shutter Priority, Time, Underwater, iAUTO
Metering Range: EV -2.0 - EV 20.0
Compensation: -5 EV to +5 EV (in 1/3, 1/2 or 1 EV steps)
White Balance Modes Auto, Cloudy, Custom, Flash, Fluorescent, Incandescent, Kelvin, Shade, Sunlight, Underwater
Burst Rate Up to 10 fps
Up to 6.5 fps
Flash
Flash Modes Auto
Fill-in
Manual
Off
Red-eye Reduction
Second-curtain Sync
Slow Sync
Slow Sync/Red-eye Reduction
TTL Auto
Built-in Flash No
Max Sync Speed 1 / 320 seconds
Flash Compensation -3 EV to +3 EV (in 1/3, 1/2 or 1 EV steps)
Dedicated Flash System TTL Groups: 4 Channels: 4
External Flash Connection Hot Shoe, PC Terminal, Proprietary, Wireless
Performance
Continuous Shooting Up to 10 fps
Self Timer 12 seconds, 2 seconds
Custom: 1-30 seconds at 0.5, 1.0, 2.0, 3.0 second intervals
Number of Shots: 1-10
Interval Recording Yes
Internal Memory None
Connectivity USB 2.0
HDMI D (Micro) (out)
1/8" Microphone (in)
Wi-Fi Capable Yes
Power
Battery 1x BLN-1 Rechargeable Lithium-ion Battery Pack, 7.6 VDC, 1220 mAh
Operating/Storage Temperature Operating
14 to 104°F (-10 to 40°C)
Humidity: 30 - 90%
Physical
Dimensions (WxHxD) 5.1 x 3.7 x 2.5" / 130.4 x 93.5 x 63.1 mm CIPA guideline compliant, excluding protrusions
Weight 1.09 lb / 497 g CIPA guideline compliant, with battery and memory card
Packaging Info
Package Weight 2.85 lb
Box Dimensions (LxWxH) 9.6 x 7.1 x 4.1"
