Power Device Type: Power Supply
Power Device Location: Internal
Input Voltage: AC 90-264 V
Input Frequency: 50/60 Hz
Input Power Connectors Quantity: 1
Input Power Connectors Type: IEC-320 C14
Output Voltage: DC 3.3/5/±12 V
Maximum Output Power: 860 W
Circuit Protection: Over Voltage Undervoltage Over Current Short Curcuit Protection
Power Adapter and Power Supply Features: Active PFC
Efficiency: 92%
Certifications: 80 Plus Platinum, cTUVus, CE, CB, FCC Class B, TÜV, CCC, C-tick
+3.3V: 25 A
+5V: 25 A
+12V: 71.6 A (859.2 W)
+5VSB: 3 A (15 W)
-12V: 0.8 A (9.6 W)
+3.3V / +5V: (125 W)
20+4-pin Main Connector: 1
4/8-pin +12V Power Connector: 2
4-pin Peripheral Power Connector: 8
4-pin Floppy Drive Connector: 2
5-pin S-ATA Connector: 12
6/8-pin PCI Express Connector: 6
Maximum Fans Supported Quantity: 1
Fans Installed Quantity: 1
Fan Diameter: 120 mm
Maximum Operating Ambient Temperature: 50 °C
Mean Time Between Failures: 100000 hr
Countries: European Union (EU)
External Color: Black
Package Type: Retail
Depth (mm): 160 mm
Height (mm): 86 mm
Width (mm): 150 mm
Warranty Products returnable: Yes
Warranty Term (month): 84 month
Warranty validation Criteria: Serial Number
Box Weight Brutto (kg): 16 kg
Pack Weight Brutto (kg): 4 kg
Pack Weight Netto (kg): 4 kg
Packs in Box: 4
Pieces in pack: 1
EAN Code: 843591020664
