Device Location: Plug-in Card
Form Factor: M.2
Storage Capacity: 120 GB
Supports Data Channel: SATA III-600
External Data Bit Rate: 6 Gbps
Certifications: UL, CE, C-Tick, BSMI, KCC, Microsoft WHCK, VCCI, SATA-IO, RoHS
Flash Memory Cell Technology: Multi-Level Cell
Lithography: 20 nm
Maximum Random Read Rate: 41000 IOPS
Maximum Random Write Rate: 80000 IOPS
Maximum Sequential Read Rate: 540 MB/s
Maximum Sequential Write Rate: 490 MB/s
Mean Time Between Failures: 1200000 hr
Solid State Drive Features: AES 256-bit Encryption
Maximum Operating Ambient Temperature: 70 °C
Minimum Operating Ambient Temperature: 0 °C
Maximum Non-Operating Ambient Temperature: 95 °C
Minimum Non-Operating Ambient Temperature: -55 °C
Maximum Input Voltage: 3.3 V
Maximum Power Consumption: 0.14 W
Minimum Power Consumption: 0.002 W
Shock Tolerance Operating: 1500G @ 0.5ms
Shock Tolerance Storage: 1500G @ 0.5ms
Vibration Tolerance Operating: 2.17G @ 5-700Hz
Vibration Tolerance Storage: 3.13G @ 5-800Hz
Height (mm): 42 mm
Warranty Products returnable: Yes
Warranty Term (month): 60 month(s)
Warranty validation Criteria: Serial Number
Pack Weight Brutto (kg): 0.06 kg
Pieces in pack: 1
