Metabones Canon EF to Sony E-Mount / NEX IV Smart Adapter Mark IV

Electronic aperture, EXIF, image stabilization, autofocus

Powered by camera body. No external power source required
True electronic integration of aperture diaphragm
Allows the camera to automatically choose aperture in P or S exposure modes

Canon EF Lens to Sony NEX Smart Adapter Mark IV
Electronic aperture, EXIF, image stabilization, autofocus

This Smart AdapterTM has the following features:
True electronic integration of aperture diaphragm - let camera automatically choose aperture in P or S exposure modes, or dial in yourself on the camera body in A or M modes.
Powered by camera body. No external power source required.
Wide open button (opposite of depth-of-field preview function) makes manual focusing easy.
The tripod foot is detachable and compatible with Arca Swiss, Markins, Photo cam ball heads.
High performance 32-bit processor and efficient switched-mode power supply.
Enhancement on MARK IV vs. MARK III:
The new design of inner housing in MARK IV has a bigger inner hole. Improving the Tilt shift lens preformance.
The inner hole is painted with matt coating. This can further reduce the internal reflection.

Product Highlights

Adapts Canon EF Lens To Sony NEX Camera
Improved Internal Structure
Retains Electronic Communication
AE, AF, EXIF & Stabilization Supported
Powered by Camera Body
Open Aperture Button for Manual Focus
Detachable Tripod Foot
Green and Advanced Function Modes
Compatible with Fully Manual Lenses
Compatible with NEX Full Frame Cameras

The Canon EF Lens to Sony NEX Camera Lens Mount Adapter Mark IV from Metabones attaches a Canon EF lens to a Sony NEX camera. It is referred to as a "Smart Adapter" because it retains electronic communication between the camera and lens and therefore provides automatic aperture control, EXIF data, image stabilization and autofocus. The adapter is powered by the camera body, so no external power source is required. The Mark IV provides the same functions as the Mark III but provides optimized performance and an improved internal structure.

The Smart Adapter IV offers two distinct operation modes: Green and Advanced modes. Each mode supports a different set of features and is selected when you mount the lens. Green mode is the default mode and it is designed to conserve battery power by limiting aperture diaphragm movements and image stabilization. Certain other functions are not available in Green Mode including Auto-Magnify MF Assist and DOF preview.

The adapter's tripod foot is detachable using an Allen wrench and compatible with Arca Swiss, Markins, Photo Clam ball heads.

Only Canon-branded lenses introduced in or after 2006 are officially supported. Autofocus speed is very slow and inadequate for most moving subjects. Autofocus may be disabled for older Canon lenses and most third-party lenses, including most Sigma, Tamron and Tokina lenses and all Contax N lenses modified by Conurus. This Smart Adapter is also compatible with fully manual lenses which have no electrical contacts. For a list of reported compatibility with specific lenses please see the Metabones website.

True electronic integration of aperture diaphragm; lets camera automatically choose aperture in Program or Shutter Priority exposure modes, or set it manually on the camera body in Aperture Priority or Manual modes.
The adapter is powered by the camera body, so no external power source is required.
Two distinct operational modes are supported by the Smart Adapter III: Green mode and Advanced mode. Green mode limits certain features and disables others in order to conserve the camera's battery power.
Wide-Open button enables aperture to remain open for clear manual focusing.
Auto-Magnify/AF Assist enlarges the image in the viewfinder for easier manual focusing. This feature requires the AF/MF switch of the Canon EF mount lens to be set to the MF position and also requires a Canon EF mount lens that supports distance information. Auto-Magnify/AF Assist is disabled in Green mode.
The tripod foot is detachable using an Allen wrench and compatible with Arca Swiss, Markins, and Photo Clam ball heads.
High performance 32-bit processor and efficient switched-mode power supply.
Compatible with EF-S lenses, however vignetting at corners may occur for certain EF-S lenses because they are designed to cover a 1.6x crop image circle and Sony NEX has a 1.5x crop sensor.
Compatible with Sony NEX full frame cameras such as the A7 and A7R. The Mark III adapter supports auto "APS-C Size Capture" with EF-S lenses as well.
Supports distance and zoom display on VG and FS series camcorders and auto magnify on lenses that support distance information
Compatible with select fully manual lenses which have no electrical contacts.
Both camera-side and lens-side of the adapter are made of brass, precision-machined and plated with chromium.
Precise fit and solid connection - lens has no play, gap or wiggling when mounted on adapter and no adjustments are required to fit your lens.
Designed to reach infinity focus while maintaining the correct registration distance required to maintain optical quality of CRC lenses or lenses with floating elements.
Metabones uses matte-black treatment to keep internal reflection to a minimum in order to maintain the maximum optical quality possible with the lens.
Satin surface finish matches lens and camera mounts.
A third party zoom lens may need to be registered with the Smart Adapter first in order to detect its maximum aperture. Autofocus is disabled for most third-party lenses.
Only Canon-branded lenses introduced in or after 2006 are officially supported. Autofocus may be disabled for older Canon lenses and most third-party lenses, including most Sigma, Tamron and Tokina lenses and all Contax N lenses modified by Conurus.

TESTIRANI FOTOAPARATI:

A7S (Mark IV supports auto "APS-C Size Capture" with EF-S lens) - Smart Adapter with firmware V0.32
A7R (Mark IV supports auto "APS-C Size Capture" with EF-S lens)
A7 (Mark IV supports auto "APS-C Size Capture" with EF-S lens)
NEX-FS700 (autofocus works only in photo mode, but is disabled in movie capture mode)
NEX-FS100 (autofocus works only in photo mode, but is disabled in movie capture mode)
NEX-EA50
NEX-VG900 (Mark IV supports auto "APS-C Size Capture" with EF-S lens)
NEX-VG30
NEX-VG20
NEX-VG10
NEX-7
NEX-6
NEX-5R
NEX-5N
NEX-5
NEX-C3
NEX-3
NEX-A6000

Note:

Vignetting at corners may occur for certain EF-S lenses because they are designed to cover a 1.6x crop image circle but Sony NEX has a 1.5x crop sensor.
Requires lenses supporting distance information.
A third party zoom lens may need to be registered with the Smart Adapter first in order to detect its maximum aperture. Autofocus is disabled for most third-party lenses.
For example, some improperly-made M42 screw mount adapters may cause a short-circuit with the electronic contacts of the Smart Adapter and cause damage to the Smart Adapter and/or camera body.

PODRŽAVA:

EF lenses (see below for list of tested lenses)
EF-S lenses (see note 1)
Image stabilization (IS)
Electronic manual focusing (e.g. EF 85/1.2L II and discontinued EF 50/1.0L)
EXIF (focal length, aperture, zoom range)
P, A, S, M exposure modes
Autofocus (see autofocus support section below)
Distance and zoom display on VG and FS series camcorders (see note 3)
Auto magnify (see note 2)
Contax N mount lenses modified to Canon EF by Conurus
Contax 645 NAM-1 adapter modified to Canon EF by Conurus
Sigma, Tamron and Tokina lenses in Canon EF mount (see note 3)

NE PODRŽAVA:

Lens correction such as peripheral shading, CA and distortion
Focus confirmation "chip" (e.g. Dandelion)
Stacking another lens mount adapter on top (see note 4)
