Panasonic TH-47LF60W monitor 47" IPS LED 700 cd/m2 24/7 operation D-link 16 mm bezel

Full HD LED LCD 47" Display
High-brightness 700-cd/m2 models with wide-viewing-angle IPS panel and LED backlight
DIGITAL LINK function enables simple installation and low system costs
Can be operated continuously for 24/7
Fan-less Design
Slim Design - 68mm (2.7") in depth, 16mm (0.7") bezel.
Built-in Speakers
Can be installed either horizontally or vertically to match the conten

UKLJUČENO:

1x monitor

The TH-47LF60W is a professional LCD Display with high brightness and excellent picture quality. The displays IPS panel provides the wide viewing angle and 700-cd/m2 brightness required for signage and other professional applications. Images are beautifully displayed even in large, brightly lit spaces such as train stations and airports. Information is clearly transmitted with highly detailed Full-HD quality, so the signage content is easy to understand.

DIGITAL LINK function

Using DIGITAL LINK enables simple installation, low system costs and makes it possible to transmit video, audio and control signals over a long distance (up to 100 m [328.1 ft]) with a single LAN cable. Easy cabling also reduces labor during setup. This provides transmission of high-quality images and sounds, as well as remote control.

24/7 Operation

The highly durable panel can be operated continuously for 24/7. It makes the display panel suitable for use all day and night in places such as restaurants and transportation facilities.

Fan-less Design

The fan-less design prevents malfunctions otherwise caused by dust particles brought in by the fan. This enables safe installation in crowded areas.

Flexible, Vertical Installation

The display can be installed either horizontally or vertically to match the content and installation location without being affected by “Mura” (unevenness). This is because the display has relatively uniform pressure distribution as compared to a TV panel, which results in far better stability. Regardless of the installation direction, the lamp life stays the same since a constant operating temperature is maintained.

Stylish Slim Design

The slim display, only 68 mm (2.7") in depth, and a narrow bezel of about 16 mm (0.7") achieve a stylish design, light weight, and thin profile.

Built-in Speaker

The speaker is built into the rear of the display. There is no need for external speakers when using content that has a soundtrack.

SPECIFIKACIJE:

DISPLAY Screen Size (Diagonal) 47 inch (1,192 mm)
Panel Type IPS/E-LED
Aspect Ratio 16:9
Effective Display Area (W x H) 1,039 mm x 584 mm
Number of Pixels (H x V) 1,920 x 1,080 pixels
Brightness 700 cd/m2
Contrast Ratio 1,300:1
Dynamic Contrast Ratio 500,000:1
Response Time 12 ms (G to G)
Viewing angle (Horizontal/Vertical) 178°
Panel Life Time Approx. 60,000 hours
Orientation Landscape / Portrait

CONNECTION TERMINAL VIDEO IN / AUDIO IN (L/R) BNC X 1 / Pin Jack (L/R) x 1 set
HDMI IN HDMI TYPE A x 2
Component IN / AUDIO IN (L/R) BNC x 1 set / Pin Jack (L/R) x 1 set
DVI-D IN / AUDIO IN (L/R) DVI-D 24-pin x 1 / Stereo mini jack (M3) x 1 (Shared with PC IN)
PC IN / AUDIO IN (L/R) Mini D-sub 15-pin x 1 (female) / Stereo mini jack (M3) x 1 (Shared with DVI-D IN)
DVI-D OUT DVI-D 24-pin x 1

CONTROL SERIAL IN / OUT D-sub 9-pin x 1 / x1, RS-232C Compatible
DIGITAL LINK RJ45 x 1 (Shared with LAN)
LAN RJ45 x 1, 100BASE-TX, Compatible with PJLink (Shared with DIGITAL LINK)
IR IN / OUT IR x 1 / x 1

AUDIO AUDIO OUT Stereo mini jack (M3) x 1
Built-in Speaker 10 W [5 W + 5 W]

ELECTRICAL Power Requirements 220 – 240 V AC, 50Hz/60Hz
Power Consumption 140 W
Power-off Condition 0.3 W
Stand-by Condition 0.5 W

MECHANICAL Dimensions (W x H x D) 1,0768 x 621 x 68 mm
Bezel Width 16 mm
Weight Approx. 16.7 Kg
Cabinet Material / Colour Plastic / Black
Mounting Method VESA Compliant 400 x 400 mm

ENVIRONMENTAL Operating Environment Temperature 0°C to 40°C
Humidity 20% to 80% (Non condensation)
