Futaba 10JH 2.4GHz 10-Channel S/FHSS Radio System with the R3008SB Receiver

The 10JH 2.4GHz 10-Channel S/FHSS Radio System with the R3008SB Receiver from Futaba supports ten channels including a variable knob, five 2-position switches, two 3-position switches, one momentary switch, two digital levers.

The system includes a jog dial and three buttons for fast easy programming. The Heli version will default to helicopter settings, with mode 2 stick operation when powered up and has a non-ratcheted throttle stick. The 128 x 64 dot LCD screen with backlight offers easy viewing of the settings.

Note: 4 AA batteries or 4-Cell NiMh pack for transmitter, Servos (Both sold separately)

System
Ten channels include one variable knob, five 2-position switches, two 3-position switches, one momentary switch, and two digital levers
Assignable switch/lever/functions (channel 5-10)
T-FHSS system with telemetry
Airplane, helicopter and glider/sailplane functions in the software
User-updatable software (requires optional CIU-2 interface, FUTM0951)
SBus programmable port
Jog dial and three buttons for fast easy programming
Transmitter also compatible with all Futaba S-FHSS air receivers
Synthesized voice with telemetry data
Vibration function for use with low battery or warning set ups
Voice output
128x64 dot LCD screen with backlight
30 model memory
Throttle cut
Servo cycle with bar graph displays
R3008SB T-FHSS telemetry receiver with external voltage port, S.Bus and S.Bus2 compatibility, 8 pwm ports
Trainer system
Airplane Menu
6 programmable mixes
9 factory-defined mixes
Flaperons with differential rate
Flap trim
Differential ailerons
Gyro sensitivity
5-point throttle and pitch curves
Throttle delay
Idle down
Glider Menu
6 programmable mixes
3 factory defined mixes
5 wing types
Gyro sensitivity
Motor menu
2 flight conditions
Heli Menu
6 programmable mixes
10 factory defined mixes
8 swash plate types
5 flight conditions w/delay
Throttle curve (4 curves, 5 points)
Pitch curve (5 curves, 5 points)
Throttle hold and delay
Swash AFR
Electronic swash ring
Multi-Rotor Menu
6 programmable mixes
Gyro sensitivity/mixing
Center stick alarm

SPECIFIKACIJE:

Transmitter
Type 2-stick, 10 channel, T-FHSS Air-2.4 GHz system
Frequency 2.4 GHz band
System T-FHSS Air, S-FHSS, switchable
Power Supply 6 V dry battery
Receiver
Type T-FHSS Air-2.4 GHz, dual antenna diversity, S.BUS system
Power Requirement 4.8 to 7.4 V battery or regulated output from ESC 1
Please Note:

When using ESCs make sure the regulated output capacity meets usage application
close
Battery Voltage Sets up with transmitter
Size 0.98 x 1.86 x 0.56" (24.9 x 4703 x 14.3 mm)
Weight 0.36 oz (10.1 g)
Packaging Info
Package Weight 2.65 lb
Box Dimensions (LxWxH) 10.315 x 10.236 x 4.724"

UKLJUČENO:

Futaba 10JH 2.4GHz 10-Channel S/FHSS Radio System with the R3008SB Receiver
10JH 2.4GHz 10-Channel S/FHSS Transmitter
R3008SB Receiver
Switch Harness
Neck Strap
